Echochange - Manual / Windows
7.1.2 Edit Access to a Station in Your List
If a connection to the desired station was not possible and the Station Not Found dialog box
appears, you can configure a direct connection to this station there. The entry will then be added to
the list of available stations and displayed in the Select a Station in Your Network dialog box. After
the station scan has been performed, an arrow symbol (->) preceding a station indicates that this
station is available online.
Station Name
The name to be displayed in the list.
H1
Establishes a connection via the H1 protocol. Specify the MAC address and the TSAP.
TCP/IP
Establishes a connection via the TCP/IP protocol. Specify the IP address and the port number.
Extended
Extends the dialog box so that you can enter additional parameters.
H1 Settings
MAC address
The MAC address of the station to be configured and diagnosed.
Use Default TSAP / Special TSAP
Here, you can indicate the TSAP for H1 or RFC 1006 connections.
TCP/IP Settings
IP Address
Here, you can indicate the IP address or the DNS name of the station to be configured and
diagnosed.
127.0.0.1 addresses the local device.
Use Default Port / Special Port
The OPC server uses port 982.
The echo devices use port 997, newer ones use 982.
If you want to configure and diagnose the station using RFC 1006, you need to enter the TSAP.
Standard
Reduces the dialog box showing only a few parameters.
Optional Product Select
These entries will be ignored.
