Echochange - Manual / Main Menu
73
URL
Here you enter the address of the NTP server.
Poll Time in Minutes
The interval at which time will be synchronized. The clock is often synchronized once an hour – 60
minutes.
9.5.6 PLC Conversion Table
The PLC protocol assignment list defines how a PLC request is routed via the second connection to
the destination connection.
The list box provides a list of all entries.
When you select an entry, the upper section of the dialog box automatically displays the associated
information.
You can now edit the Source and Destination fields.
Then click the Update -> button to update the selected entry.
With Add ->, you can add a new entry with the specified settings to the list.
The <- Delete button deletes the selected entry.
If you click Clear Table, all entries will be deleted without confirmation prompt.
Any changes you make will only be applied after you close the dialog box with OK.
Procedure
If a request with a corresponding protocol arrives at a specified address, the data is routed over the
second connection set to the respective protocol and forwarded to the destination address. Frames
with requests that do not match the specified PLC protocol and the other settings are ignored.
If no matching entry is found, the PLC request is replied with “Element not found”.
If you set a CLX connection as the destination, use Browse to select the name online from the PLC.
The associated data type is determined automatically. This procedure should be used for CLX in
order to avoid incorrect settings.
The entries refer to the selected protocol and apply to all connections with that protocol.
Input Fields
The individual input fields have the following meanings:
Source
The parameters and the address of the passive source connection (left
side).
Destination
The parameters and the address of the active destination connection
(right side).
PLC Protocol
Specifies the PLC protocol of the connection.
Element
Specifies the data area of the connection. The list depends on the
selected protocol.
Block
The data block number for S5 and S7.
Address
The starting address
Length
Number of elements of the selected type.
Typ
Data type; this parameter must be correctly set for CLX connections.
Destination
Symbol
For CLX connections, a symbolic destination address must be entered.
The -> Browse button allows browsing the online PLC
-> Browse
Browses a CLX PLC online
Only one DBx per Connection is allowed in the PLC conversion table.
