9.5.3 Device System Settings
Any changes to these parameters will take effect immediately.
Free bytes of the S5 AP Ack aren't mirrored
In the acknowledgment frame of the S5 AP header, not all the bytes are relevant. With this check
box, you can choose whether you want these bytes to be filled with the bytes of the request, or set
to 0.
Reset Diagnostics
Resets all internal diagnostic counters to 0.
9.5.4 Diagnose of Default Connections
If you are using default connections, you can diagnose them here. Up to 7 default connections can
be used (2 x port 990, 5 x port 991). Each default connection is displayed with the following
parameters:
Type
Always IP because default connections are only available for TCP/IP.
Name of the Connection
The connection name is numbered from Default 1 to Default 7.
Job
The job numbers are assigned automatically.
Anzw
The display word in hexadecimal code
Anzw Text
The display word in plain text
Network
Displays the current status of the connection. The following messages can be displayed: OK, Wait
for ACK, No connection
Send + Rec
Here the number of transmitted and/or received frames is displayed.
9.5.5 Clock Settings
How to Set the Clock
To set the internal clock, enter the hour, minute, second, day, month and year. Then click the Set
button to apply the displayed values to the echo device. The day of the week is then shown
automatically. The clock continues to run as long as no entries are made. Entries stop the refreshing
of the display. If NTP is selected, the clock is set automatically.
Time Location
Select the correct time zone.
NTP Settings
Use NTP Service
Select this check box to obtain the time settings over the Internet.
Many institutions provide master clocks based on UTC time (Coordinated Universal Time). To provide
the local time, select the corresponding time zone. In this case, the clock will also be adjusted to
daylight saving time and take into account the leap seconds that occur occasionally at the end of a
year.
