Echochange - Manual / Main Menu
9.1 File
The File menu provides the following functions:
Load configuration from file
This menu item is used for loading the parameter file to the device.
• Click this menu item to open the Windows dialog box: Open File...
• Select the desired file and click the Open button.
• A new dialog box appears: Copy from File into the Device
• Here you can choose if you want to overwrite the MAC address, the IP address and the IP settings
in the device.
• When you click the OK button, the parameters are irreversibly overwritten in the device.
Store configuration to file
Using this menu item, you can save all the device's parameters to a parameter file.
Store configuration to SD-Card
Using this menu item, you can save all the device's parameters to a sd-card in the device.
Attention: The configuration stored on the SD-card will replace the current configuration when the
device restarts.
Refresh
Reestablishes the configuration connection to the device. If a password has been set, the password
needs to be re-entered to allow editing.
This function is particularly useful for serial links. It allows rereading the list of connections from the
module. This is necessary, for example, if the connection cable is plugged into a different module.
The Connections list is cleared and rebuilt with the current connections.
Print
For documentation purposes, you can output a list of the connections.
The list is printed on the system's default printer.
Close Window
Closes the configuration of the device and switches to the Configuration window.
9.2 Connection
This menu provides the following options:
Switch on/off
You can disable a connection if it is not intended for communication. Thus, it is possible to disable it
temporarily without having to delete and redefine it. See Disable Connection.
To use this function, master access is required.
New Connection
Here you can enter a new connection. The New Connection dialog box appears. First, select the
connection name and type. Then enter the required parameters.
When you save the connection, the connection parameters take effect immediately.
To use this function, master access is required.
Edit Connection
Here you can edit the parameters of the selected connection. The Edit Connection dialog box
appears.
To use this function, master access is required.
