63Main Menu
Echochange - Manual / Main Menu
63
Copy Connection
You can copy the connection. The Copy Connection dialog box appears. Before clicking Save,
please keep in mind to rename the copied connection.
To use this function, master access is required.
Delete Connection
The connection is deleted after you confirm the prompt in the Delete Connection dialog box.
To use this function, master access is required.
9.3 Diagnostics
This menu provides the following options:
Show one Connection
The connection selected in the Connections list can be monitored. The Connection Diagnostics
dialog box appears.
Signal Device
When you click this menu item, all the LEDs will blink for about 2-3 seconds. This shows you which
device the NetCon is connected to.
IP/NetStat
Opens the IP/NetStat dialog box, which displays an overview of the connections entered in the
runtime system.
Start Capture Network
If the device is equipped with a SD-card, then this menu entry starts the capture of the data traffic at
both Ethernet interfaces. The capture ends after ca. 25 hours, the stop command or when the device
restarts. If there is already one capture running, then no additional is started.
Stop Capture Network
This menu entry terminates a previously started capture of network traffic.
Logger
Opens the Logger window where the recorded messages are displayed.
This window can be opened in parallel to the software application. You can continue to configure and
use the software while the Logger window is open.
Logger Settings
Opens the Logger Settings dialog box. There you can select the events that will be recorded by the
Logger.
The file and memory settings for the Logger are made under Settings in the Logger window.
Free place on sd-card
If a memory card is inserted, the dialog box shows the size of the memory card and the free memory
space (version 7.0 and higher).
9.3.1 echochange Connection Diagnostics
The dialog box shows the online diagnostics for an echochange connection.
The diagnostics window is divided into two parts:
the left side or passive side
the right side or active side
The number of transmitted frames and bytes as well as the number of received frames and bytes are
