Echochange - Manual / Main Menu
shown for each side.
In addition, the window shows you the number of disconnects and the connection status.
The PLC status indicates whether communication with the PLC is OK or whether problems have
occurred.
The contents are cyclically refreshed.
9.3.2 TCP/IP Stati
The dialog box displays a list of the TCP/IP connections and provides diagnostics.
The individual columns show details about the configuration and status.
The contents are cyclically refreshed.
To scroll through the list, use the “Page...” buttons.
9.3.3 Logger
Here you can select different options to specify the information you want to log. The log data is
displayed in the Logger window.
Error
Error
Error
Log all types of errors in the Logger, except PLC errors.
PLC Element Error
If an area in the PLC does not exist or if a requested area is too
small, a corresponding entry is made in the Logger. This also
applies to all other errors generated by the PLC.
SQL Error
Logs all types of SQL connection errors in the Logger.
SQL Error Log File
The file name for logging SQL errors
Status
The reparameterization of connections and the login for reparameterization are recorded by the
Logger.
Status
Connection
Parameterization
An entry is logged whenever connection parameters are
changed and saved.
Connection Status
Change
An entry is logged whenever the status of a connection
changes.
PLC Data
The parameters of the respective PLC requests from the server to the PLC are recorded by the
Logger.
PLC data
Send
Content of the frames in write direction. The area that is written to is
logged.
Send Data
The data content of the frames in write direction is logged.
Receive
Content of the frames in read direction. The area that is read is
logged.
Receive Data
The data content of the frames in read direction is logged.
SQL Data
The requests and data of the Collect destination connection are recorded by the Logger. This can be
