Specifications
10
TABLE 7. Readers, Inputs, and Outputs
Readers, Inputs, and
Outputs
Reader Ports 16
Reader Support RM readers or RM reader modules
Reader Technologies Supported
Multi-Technology
Proximity
Smart Card
Wiegand
Magnetic Stripe
HID iCLASS
Supervised Inputs 32, double 1 K ohm resistors
Outputs 16, 1A nominal (max 2.5A)
24 VDC lock power per output
Class 2 power limited dry contact
operation, selectable per output.
Output Protection Individually fused with
resettable PTC fuses
Fire Alarm Interlock Per lock output, individually settable via
jumpers
Tamper Switches Two, front and rear cover
TABLE 8. Regulatory Specifications
Regulatory
Tested and certified by ETL per ANSUI/UL standard 294-2004
Tested and certified by ETL per ANSUI/UL standard 1076-2004
FCC Part 15 Class B
