Specifications
11
TABLE 9. Specific considerations when using the iSTAR Pro 4U Rack Mount as an
intrusion detection / burglar alarm system, per ANSI/UL 1076
UL 1076 Intrusion Detection / Burglar Alarm Recommendations
Recommended Arm/Disarm
Device
RM2L-4000 multi-technology reader
with keypad & display, to provide visual
indication of individual zone status to
operator
AC Power Source Must use a UL-approved UPS, sized to
provide 4 hours of full operation when
main AC power is not present
Local Sounder Recommend to install local horn,
activated when the zone is in alarm
Maximum number of
protection inputs per zone
32
Maximum number of non-
protection inputs per zone
32
Maximum number of readers
per zone
16
