August 3, 2019 35
• Battery symbol on home screen is yellow
o Battery is low or charge/discharge current is close to the programmed limit (which is ok)
• Grid symbol on home screen is yellow
o Grid parameters are out of specified range or grid is down
• System has restarted
o Happens if: System is overloaded, Battery voltage is greater than 61V, or Software update
• Batteries were connected backwards
o Battery fuse has blown (Call us)
• Why is LCD screen still on when power button is off?
o If PV or Grid power, LCD stays on but inverter and loads are off.
• The Batt % meter is not reaching 100%
o System needs to go through a small discharge/charge cycle to first calibrate battery
• Generator setup is reading 0Hz
o Select “General Standard” instead of UL1741. Then widen the voltage range to 53Hz-65Hz.
• Color Touchscreen is Frozen
o Press and hold the escape button [] for 7-10 seconds
Sol-Ark 8K Error Codes
Overloaded the Load Output, reduce loads. Wiring Short on
the AC Side can also cause this error.
