sol-ark 8K - Screens; Home Screen (Touchscreen); Detailed Volts View; Grid Column

August 3, 2019 27
Screens
• Home Screen (Touchscreen)
• Detailed Volts View
o Top row = Total power for column
o Middle Row = Line 1/PV1 voltage, Amps, and Watts (note: PV Voltage not to exceed 500)
o Bottom Row = Line 2/PV2 voltage, Amps, and Watts (note: PV Voltage not to exceed 500)
o Batt Temperature will show -20°C if temperature sensor is not connected.
o Batt SOC % = % batteries are charged
o DC Temp = Temperature of DC conversion electronics
▪ Batt → AC
▪ PV → Batt
▪ AC → Batt
o AC Temp = Temperature of AC conversion electronics
▪ Batt → AC
▪ PV → AC
o Grid Column
▪ If selling to grid, Grid Watts = negative
▪ If buying from grid, Grid Watts = positive
▪ Note: If these values are reversed, current sensors may have been installed incorrectly (reverse
polarity).
▪ HM = Power detected by the external current sensors on entire home L1 & L2
▪ LD = Power detected using internal sensors on AC grid in/out breaker
Settings
Detailed Volts
View
PV Graphical View
Solar Power
Production
Grid Power
Sell(negative)/Buy(positive)
Load Power
Consumption
Battery Power
Charge(negative)/Discharge(positive)
Grid Graphical
View
Hold 3s to Force Smart Load
