Common Battery Application Notes
Sol-Ark PCC-230 Battery
Batt Capacity: 230Ah x #Parallel_Batteries
(1 parallel = 4 Batt in series, 2 = 8 Batt, 3 = 12 Batt, 4 =16 Batt)
Max A Charge: 100A x #Parallel_Batteries
Max A Discharge: 100A x #Parallel_Batteries
Max A Grid Charge: 50A x #Parallel_Batteries
TEMPCO: -5mV/C/Cell
Float V: 53.6V
Absorption V: 56.8V
Equalization V: 56.8V
Equalization Days: 90
Equalization Duration: 3 Hours
Recommended Shutdown V / Percentage: 41.0V & 20%
Recommended Low Batt V / Percentage: 45.0V & 35%
Recommended Restart V / Percentage: 52.0V & 50%
Battery Resistance: 6mOhms (8 Batt) or 3mOhms (16 Batt)
Battery Charge Efficiency: 99%
Generation 2 Fortress Battery-eVault16.5
Batt Capacity: 360Ah x #Parallel_Batteries
Max A Charge: 150A (100A for life) x #Parallel_Batteries
Max A Discharge: 160A x #Parallel_Batteries
Max A Grid Charge: 100A x #Parallel_Batteries
TEMPCO: 0mV/C/Cell
BMS Lithium Batt: Not Selected
Float V: 54.4V
Absorption V: 54.6V
Equalization V: 56V
Equalization Days: 30
Equalization Duration: 1 Hours (tops off battery)
Recommended Shutdown V / Percentage: 51.3V & 20%
Recommended Low Batt V / Percentage: 51.7V & 30%
Recommended Restart V / Percentage: 51.9V & 40%
Battery Resistance: 5mOhms
Battery Charge Efficiency: 99%
Simpliphi Power: PHI 3.5 Battery 48V
Batt Capacity: 69Ah x # Batt
Max A Charge: 34A x # Batt (20A for better lifespan)
Max A Discharge: 60A x # Batt (34A for better lifespan)
Max A Grid Charge: 20A x # Batt
TEMPCO: 0mV/C/Cell
BMS Lithium Batt: Not Selected
Float V: 49.5V
Absorption V: 54.4V
Equalization V: 56V
Equalization Days: 30
Equalization Duration: 1 Hours (tops off battery)
Recommended Shutdown V / Percentage: 50.2V & 20%
Recommended Low Batt V / Percentage: 50.6V & 30%
Recommended Restart V / Percentage: 51.0V & 40%
Battery Resistance: 8mOhms
Battery Charge Efficiency: 98%
Time
Watts
SOC
GridCharge
1:00AM
1500*Par_Batts
50%
5:00AM
1500*Par_Batts
50%
9:00AM
1500*Par_Batts
50%
1:00PM
1500*Par_Batts
100%
4:00PM
1500*Par_Batts
50%
9:00PM
1500*Par_Batts
50%
Time
Watts
SOC
GridCharge
1:00AM
6000*Par_Batts
40%
5:00AM
6000*Par_Batts
40%
9:00AM
6000*Par_Batts
40%
1:00PM
6000*Par_Batts
40%
5:00PM
6000*Par_Batts
40%
9:00PM
6000*Par_Batts
40%
Time
Watts
SOC
GridCharge
1:00AM
1000*Batts
40%
5:00AM
1000*Batts
40%
9:00AM
1000*Batts
40%
1:00PM
1000*Batts
40%
5:00PM
1000*Batts
40%
9:00PM
1000*Batts
40%
These settings will charge the batteries off solar only.
Discharge the batteries down to a maximum of 50% full.
Limited To Home mode will not sell to the grid from the
batteries (only the home will use battery power). The
100% time slot is to ensure that the batteries are
properly cycled each day.
These settings will charge the batteries off solar only.
Discharge the batteries down to a maximum of 40% full.
Limited To Home mode will not sell to the grid from the
batteries (only the home will use battery power).
These settings will charge the batteries off solar only.
Discharge the batteries down to a maximum of 40% full.
Limited To Home mode will not sell to the grid from the
batteries (only the home will use battery power).
