SolarEdge SE2500H - Page 75

SE2200H SE3000H SE3500H SE3680H SE4000H SE5000H SE6000H Units
OUTPUT
Rated AC Power Output 2200 3000 3500 3680 4000
5000
(1)
6000 VA
Maximum AC Power Output 2200 3000 3500 4000 4000 5000
(1)
6000 VA
AC Output Voltage (Nominal) 220 / 230 Vac
AC Output Voltage Range 184 - 264.5 Vac
AC Frequency (Nominal) 50 / 60 ± 5 Hz
Maximum Continuous Output Current 10 14 16 16 18.5 23 27.5 A
Maximum Continuous Overcurrent
Protection
10 14 16 16 18.5 23 27.5 A
Residual Current Detector / Residual
Current Step Detector
300 / 30 mA
Inrush current AC (Peak/Duration) 2.8 / 20
Aac
(rms) /
ms
Maximum Output Fault Current 38 A
Power Factor Range 1 (adjustable from -0.9 to +0.9)
Total Harmonic Distortion < 3 %
Protective class Class I
(1)
SE5000H is limited to 4600VA in Germany
SolarEdge-Three Phase Inverter Specifications (Europe & APAC) MAN-01-00239-1.1
1
Technical Specifications - Single Phase Inverters with HD-Wave Technology
(Europe & APAC)
