SE3K SE4K SE5K SE6K SE7K SE8K SE9K SE10K SE12.5K Unit
Additional Features
Supported
Communication
Interfaces
(1)
RS485, Ethernet, ZigBee (optional), Wi-Fi (optional), Built-in
GSM (optional)
Smart Energy
Management
Export Limitation, Home Energy Management
Arc Fault
Protection
Integrated, user configurable (according to UL1699B)
Standard Compliance
Safety IEC-62103 (EN50178), IEC-62109
Grid connection
standards
(2)
VDE 0126-1-1, VDE-AR-N-4105, AS-4777, G83 / G59
Emissions
IEC61000-6-2, IEC61000-6-3, IEC61000-3-11, IEC61000-3-12,
FCC part15 class B
WEEE, RoHS Yes
Installation Specifications
AC output / Gland
Diameter / Wire
Cross Section
15-21 mm / Solid wire 2.5-16 mm
2
, Stranded wire 2.5 - 10
mm
2
DC input
2 MC4 pairs
(3)
Dimensions
(WxLxH)
540 x 315 x 260 mm
Weight 33.2 kg
Operating
temperature range
(4)
-20 - +60 (M40 version -40 to + 60) °C
(1)
Refer to Datasheets > Communications category in Downloads page for specifications of
communication options: http://www.solaredge.com/groups/support/downloads
(2)
For all standards refer to the Certifications category in
http://www.solaredge.com/groups/support/downloads.
(3)
You can connect strings in parallel to a single input as long as the cumulative current does not exceed
45A.
(4)
For inverter power de-rating refer to the application note at the following link:
http://www.solaredge.com/files/pdfs/se-temperature-derating-note.pdf
Technical Specifications - Three Phase Inverters (Europe &APAC) 103
Three Phase System MAN-01-00507-4.2
