6. For the switch/router side, use a pre-crimped cable or use a crimper to prepare an
RJ45 communication connector.
7.
Connect the cable RJ45 connector to the RJ45 port of the Ethernet switch or
router.
You can connect more than one inverter to the same switch/router or to different
switches/routers, as needed. Each inverter sends its monitored data
independently to the SolarEdge monitoring platform.
NOTE
There are no LED indicators on the Ethernet connector, if the inverter is
not communicating with the monitoring platform through a LAN refer
to
Troubleshooting Communication
on page 80.
8.
The inverter is configured by default to LAN. If reconfiguration is required:
a. Verify the ON/OFF switch is OFF.
b. Verify the AC is on.
c.
Close the cover and turn ON the Connection Unit.
WARNING!
ELECTRICAL SHOCK HAZARD. Do not touch uninsulated wires when
the Connection Unit cover is removed.
d.
Use the SolarEdge SetApp to access the Commissioning main menu screen
as described in
Communication
on page 45.
e.
From the main menu tap Communication. The Communication screen is
displayed:
f.
Select the following to configure the connection:
Server è LAN
LAN è DHCP è Enable
9.
Verify the connection, as described in
Verifying the Connection
on page 73.
NOTE
The system automatically establishes communication with the
monitoring platform as it is configured to LAN by default.
Chapter 6: Setting Up Communication 69
Three Phase Inverter with Synergy Technology Installation MAN-01-00402-1.2
