6. In the “cosφ(P)” menu, select the specication for the reactive power feed-in required
by the grid operator:
Setting Description
On Standardised reactive power feed-in
Inactive
No reactive power feed-in (cos φ=1)
– Press to conrm your entry.
7. In the “Validation” menu, check your entries. You can complete initial start-up after-
wards by pressing
. The main menu will then be displayed (see 6.3.2 Main menu;
page 86).
6 Operation
6.1 Graphics display
The graphics display on the front of the inverter shows the inverter’s system variables,
status information, and failure messages. The display allows you to learn the current de-
vice status, access the integrated data logger, and enter various settings for the inverter.
Navigate the various menus using the three buttons under the display.
The display is backlighted to improve readability when lighting is poor. Activate the back-
light by pressing any of the buttons. The backlight remains active for 180 seconds after
the buttons were last used.
