SolarMax 15MT2 - Electrical Connection Overview

71
Installation plate MT series
235 mm
100 mm
1 2
1
Recesses for lock with splint
2
Hole Ø 10mm for padlock (against theft)
4.6 Electrical connection
The MT series inverters have the following connection options:
1 2 3 44 5 6 7
