13 Specications
13.1 Specications
8MT2 10MT2 13MT2 15MT2 13MT3 15MT3
Input
values
MPP voltage range 250…
750V
250…
750V
250…
750V
250…
750V
250…
750V
250…
750V
Minimum voltage for
rated output power
300V 290V 370V 430V 280V 320V
Maximum DC voltage 900V 900V 900V 900V 900V 900V
Maximum DC current 1 x 18A /
1 x 9A
2 x 18A 2 x 18A 2 x 18A 3 x 16A 3 x 16A
Number of MPP trackers 2 2 2 2 3 3
Max. PV generator output
per MPP tracker
9’000W 9’000W 9’000W 9’000W 9’000W 9’000W
String connections 1 x 2 / 1
x 1
2 x 2 2 x 2 2 x 2 3 x 2 3 x 2
Connection type MC 4 MC 4 MC 4 MC 4 MC 4 MC4
Output values Rated output power at
cos(φ) = 1
8’000W 10’000W 13’000W 15’000W 13’000W 15’000W
Maximum apparent output
power
8’000
VA
10’000
VA
13’000
VA
15’000
VA
13’000
VA
15’000
VA
Nominal mains voltage 3 x 400V 3 x 400V 3 x 400V 3 x 400V 3 x 400V 3 x 400V
Maximum AC current 3 x 12A 3 x 16A 3 x 20A 3 x 22A 3 x 20A 3 x 22A
Mains nominal
frequency / range
50Hz / 45Hz…55Hz
Power factor cos(φ)
Adjustable from 0.8 overexcited to 0.8 underexcited
Distortion factor at rated
output power
< 3 %
Connection type Amphenol
Grid connection Three-phase (3 /N / PE)
Efciency Max. efciency 98.0 %
European efciency 97.5 %
Power input Own consumption night 0W
Ambient
conditions
Protection class compliant
with EN 60529
IP65
Ambient temperature range −20°C…+60°C
Ambient temperature range
at rated output power
−20°C…+50°C
Relative humidity 0…98% (no condensation)
Conguration Display Graphic LC display with backlight and status LED
Circuit type two-stage, transformerless (no galvanic isolation)
Data logger Data logger for energy yield, peak output, and operating dura-
tion for the last 31 days, 12 months and 10 years
Fault current monitoring Internal, AC/DC sensitive
