SolarMax 3600SP - Technical Data

30
9 Technical Data
3600SP 4000SP 4600SP 5000SP
Input values MPP voltage range 90 ... 580 V 90 ... 580 V 90 ... 580 V 90 ... 580 V
Maximum DC voltage 600 V
Maximum DC voltage
for startup
90 V
Minimum DC voltage
for shutdown
90 V
Maximum DC current 26 A (2 x 13 A)
Maximum DC short
circuit current
30 A (2 x 15 A)
Maximum PV output/
MPPT
MPPT1: 3900 W
MPPT2: 3900 W
MPPT1: 4400 W
MPPT2: 4400 W
MPPT1: 5060 W
MPPT2: 5060 W
MPPT1: 5500 W
MPPT2: 5500 W
Number of MPP
trackers
2
Number of string
connections
2 x 1
Connection type Amphenol H4 (type MC4)
Output
values
Rated output power 3 600 W 4 000 W 4 600 W 5 000 W
Maximum output
apparent power
3 680 VA 4 400 VA 4 600 VA 5 000 VA
Maximum AC current
16,0 A 19,1 A 22,0 A 23,8 A
Mains nominal voltage
230 V
Mains voltage range 160 V ... 300 V
Mains nominal
frequency
50 Hz / 60 Hz
Mains frequency range 45…55 Hz / 55 Hz ... 65 Hz
Power factor 0.8i – 0.8c
Distortion factor at
rated output power
< 3 %
Power input at night 1 W
Connection type Connector
Eciency Max. eciency 97, 5 % 97, 5 % 97,6 % 97,6 %
Europ. Eciency 97,2 % 97,2 % 97, 3 % 97, 3 %
Environment Protection lass IP65
Ambient temperature
range (for rated power
output)
– 25 … + 60°C (derating over 45°C)
Relative humidity 0 … 100 % (not condensing)
Cooling Natural convection
Max. operating level
above sea level
2000 m (without derating) / 4 000 m maximal
Audible noise
emissions
<30 dB(A) @ 1 m
