Technical Specification
38
Control:
Displays ...............................................LCD in 4 – Field selectable languages and 8 LEDs.
Keypad.................................................6 keys for easy setting
Aux Contact – Immediate....................1 C/O, 8A, 250VAC, 2000VA
Aux Contact – End Of Acceleration.... 1 C/O, 8A, 250VAC, 2000VA
Fault Contact .......................................1 C/O, 8A, 250VAC, 2000VA
Insulation Alarm Contact (option)…. .1 C/O, 8A, 250VAC, 2000VA
Communication ...................................RS 485 with MODBUS protocol for full control and supervision.
............................................................. Consult factory for other communication protocol.
Temperatures
................................ Operating -10˚ to 50˚C
Storage -20˚ to 70˚C
Standards:
Dielectric Test .....................................2500VAC
Degree of Protection............................IP 20 for frame size A
IP 00 for frame sizes B, C, D, E, F, G
Pollution Degree..................................3
EMC Emissions EN 55011 CISPR 11 Class A
Immunity EN 55082-2 ESD 8KV air, IEC 801-2
Electric RF field 10 V/m, 20-1000Mhz, IEC 801-3
Fast transients 2KV, IEC 801-4
Safety EN 600947-1 Related to safety requirements.
UL508C
Normal Service Conditions:
Altitude................................................Up to 1000m. For equipment to be used at higher altitudes consult Factory.
Humidity.............................................. 95% at 50˚C or 98% at 45˚C.
Fan and Starter Consumption Ratings:
Size A (8-31A) ....................................No fan Total starter Consumption ..................... 150VA
Size A (44-72A) ..................................Fan 35 VA Total starter Consumption ..................... 185VA
Size B ..................................................Fan 60 VA Total starter Consumption ..................... 210VA
Size C ..................................................Fans 105 VA (35VA x 3) Total starter Consumption ..................... 255VA
Size D, E, F, G.....................................Fans 150 VA (50VA x 3) Total starter Consumption ..................... 300VA
