Solcon RVS-DN User Manual

Parameter Settings
25
Press Mode
To advance to:
MAIN PARAMETERS
Press Select
Press

keys to set Starter’s connection type.
(see Appendix for: Inside Delta description).
CONNECTION TYPE
LINE / INSIDE DELTA
Press Select
Press

keys to set Starter’s FLC.
(see RVS-DN ratings – Page 3).
STARTER FLC
105 AMP
Press Select
Press

keys to set motor’s FLA
Range: 50-100% of “STARTER FLC”
MOTOR FLA
105 AMP
Press Select
Press

keys to set Under Current Trip.
Range: 0 = OFF, 20-90% of FLA
UNDERCURR. TRIP
0% OF FLA
Press Select
Press

keys to set under Current Trip Delay.
Range: 1-40 sec.
UNDERCURR. DELAY
10 SEC.
Press Select
Press

keys to set Over Current Shear-pin.
Range: 200 – 850% of FLA
O/C – SHEAR PIN
850% OF FLA
Press Select
Press

keys to set O/C Shear-pin Delay.
Range: 0.5-5 sec.
O/C DELAY
1.5 SEC.
Press Select
Press

keys to set Overload Trip Current.
Range: 75-150% of FLA
OVERLOAD TRIP
115% OF FLA
Press Select
Press

keys to set Overload Delay
at 500% of motor FLA
Range: 1-10 sec.
OVERLOAD DELAY
4 SEC – AT 5 FLA
Press Select
Press

keys to set Under Voltage Trip.
Range: 120-600V
UNDERVOLT. TRIP
300 VOLT
Press Select
Press

keys to set Under Voltage Trip Delay
Range: 1-10 sec.
UNDERVOLT. DELAY
5 SEC.
Press Select
Press

keys to set Over Voltage Trip.
Range: 150-750V (can not be set below Under
Voltage).
OVERVOLT. TRIP
480 VOLT.
Press Select
Press

keys to set Over Voltage Trip Delay.
Range: 1 – 10 sec.
OVERVOLT. DELAY
2 SEC.
Press Select
To store selected parameters, press Store key.
STORE ENABLE
MAIN PARAMETERS
Note: Storing selected parameters is possible
only when Stop or Run LED are lit.
Storing cannot be done when Start, Soft
Stop, Slow Speed, Energy Save, or Fault
LED are lit.
When parameters have been correctly stored, the LCD
will read:
DATA SAVED OK
This concludes MAIN PARAMETER settings.
Pressing Select key after “Data Saved OK” returns to
the first display in this mode.
Note: In case of a failure in parameter storing,
the LCD displays:
STORAGE ERROR
Press Select button again until “Store Enable Main
Parameters” returns. Then press
Store
key until “Data
Saved OK” appears.
