Solcon RVS-DN User Manual

Dimensions (mm)
50
FRAME SIZE – E 1100, 1400, 1800A FRAME SIZE – F 2150A
FRAME SIZE – G 2400A, 2700A, 3000A, 3500A
Starter
Type
Current FLC
(Amp)
Frame
Size
Width Height Depth
Weight
(Kg.)
RVS-DN
8, 17 A 150 310 170 4.5
31 A 150 310 170 6
44, 58, 72 A 150 310 217 7.4
105, 145, 170 B 274 370 222 15.1
210, 310, 390 C 590 500 290 44.8
460, 580, 820 D 623 660 290 65
1100, 1400, 1800 E 723 1100 361 170
2150 F 750 1300 392 235
2400, 2700, 3000,
3500
G 900 1300 360 350
FAN
C/T C/T
10
12-for 1800A
85
315
268
370
-for 1100,1400A
FAN FAN FAN
9
20
20
M8
80
L
LL
123
UV
W
131.5
45
45
16.5
10״
723
9 ״
230 230
230 230 230
29
47.5
712
778
786
1100
131.5 230 230
8
9 ״
149 165
230230191.5
32
1
LLL
WVU
8
R5.5
12
14״
10״
12
FAN
238238238
60
45
1300
1021
238 238
750 330
280
392
1105
96
M10
100
33
47.5
30
30
M10
10.5״
22.5
R7
285 285
64
20
14״
11
12
12
900
285 285 285
165
142
60
45
10651
75 250 250 250 207
410
142
88 33
L
L
2
L
31
UV
W
1300
1022

Solcon RVS-DN Specifications
