MIG 250GS Operating manual
12.0 Technical Specifications
Specifications MIG/MAG MMA
Model no. MIG 250GS
Part no. 11299757
Power voltage Single phase 230 V ±15 %
Frequency 50/60 Hz
Rated input current (Ieff) 27.2A
Output current 50 A to 250 A 50 A to 220 A
Output Voltage 16.5 V to 26.5 V 22 V to 28.8 V
Duty cycle
30 % – 220
35 % 250 –
60 % 200 180
Power factor 0.73
Efficiency 80 %
Wire speed 80 to 550 inch/min
Wire spool diameter 270 mm
Wire diameter 0.8/1.2 mm
Housing shielding grade IP21
Insulation grade F
Suitable thickness 0.8 mm above
Dimensions L × W × H 900 × 458 × 960 mm
Weight approx. 45 kg (Power source)
Wire feeder Built in
Standards CAN/CSA-E60974-1
