MIG 250GS Operating manual
14.0 Assembly Instructions Cart
Cart assembly requires the machine to be placed on its side on a soft raised surface by 2 persons to enable access to the bottom of the
Left trolley
support
Trolley
Front wheel Rear wheel
Rear wheel
Wheel
Right trolley
support
Tool tray
Cylinder support
Washer
Axle
Power
source
Power
source
Circlip
1
3
2
4
