036
MIG 250GS Operating manual
15.0 MIG250GS machine explosive view
No. Part Number Description Qty.
1 R372900000100 Hinge 4
2 R1911569701A0 300 series left lower cover 1
3 R401800000400 Central socket 1
4 R401608100100 Quick socket / KDZ50 2
5 R371904001500 Self-locking buckle / M20 (black) 1
6 R1590114001A0 MIG 250GD/NBC 250G front lower plastic panel 2
7 R1504146201A0 MIG 250GN front panel 1
8 R372103220102 Double drive wire feeding mechanism 1
9 R2412160001A0 MIG 250GN rectied output connector 1
10 R030202002701 Reactor 1
