SOLIS Master Top - Legend, Control Panel, Control Indicators

SOLIS MASTER TOP
Operating Instructions
69
Legend:
1 Removable water container
2 Warming plate for cups
3 Swiveling steam and hot-water nozzle
with cappuccino nozzle
4 Hot-water/steam knob
5 Cup tray
6 Removable drip tray with fill-level indicator
7 Removable container for waste coffee
8 Bean-container with cover
9 Funnel for ground coffee with cover
10 Grinding adjustment
10a Indicator for grinding adjustment
11 Main switch O–I
12 Built-in rotating ring
13 Control panel
14 Service door (2 parts)
15 Brewing unit with drawer for waste coffee
16 Removable and adjustable coffee delivery system
17 Accessories: measuring spoon, multi-tool
adjustment knob and cleaning brush
18 Panel cover
