Solplanet SOL APOLLO Series - Page 36

UM0027_ SOL APOLLO Series 7.4-22K_EN_V02_0523 35
Install the incoming AC supply cable
There are two options for installing the incoming AC supply cable.
Option 1:
Through the cable gland (A) located on the bottom of the enclosure.
Figure 19
Option 2:
Drilling a hole through the rubber seal located on the rear of the enclosure (A).
Figure 20
▪ All electrical installations must be done in accordance with all
local and national rules.
▪ Ensure that all power sources have been electrically isolated
before any electrical terminations have been made.
