SOLTEK SL-52D2 - CPU 2.5 X Clock Setting (Red Caps); Pentium Ð 150;166 Mhz; CPU 3.0 X Clock Setting (Red Caps); Pentium Ð 180;200 Mhz

Hardware Installation 7
CPU 2.5X Clock Setting (Red Caps)
Pentium – 150/166 MHz
AMD K5 – PR150/RP166 MHz
JP21 JP23
1
AMD K5 – PR150/60
Intel Pentium 150/60
AMD K5 – PR166/66
Intel Pentium
(or MMX) 166/66
SRAM Slot
CPU
JP5
JP7 JP9
JP21 JP23
1
1
1
JP6
1
JP17
JP18
JP8
JP21 JP23
1
Figure 2Ð3. CPU Type Configuration
CPU 3.0X Clock Setting (Red Caps)
Pentium – 180/200 MHz
JP21 JP23
1
JP21 JP23
JP21 JP23
1
Intel Pentium 180/60
Intel Pentium
(or MMX) 200/66
SRAM Slot
CPU
JP5
JP7 JP9
1
1
1
JP6
1
JP17
JP18
JP8
Figure 2Ð4. CPU Type Configuration
