SOLTEK SL-52D2 - LPT1: Parallel Port; COM1;COM2: Serial Port Connectors

Hardware Installation 17
LPT1: Parallel Port
The system board provides a 2x13-pin parallel port
connector, LPT1. Attach parallel port cable to this
connector.
COM1 /COM2: Serial Port Connectors
The system board has two 2x5-pin serial port connectors,
COM1 and COM2. Attach COM1/COM2 cables to these
connectors.
+
–
LPT1
1
COM2 COM1
1
1
