SOLTEK SL-52D2 - Power Connector

Hardware Installation 19
Power Connector
The power connector has two 6-pin male header connectors.
Plug the dual connectors from the power directly onto the
board connector while making sure the black leads are in
the center.
P9
P8
Power Connector
+
–
