SOLTEK SL-52D2 - Intel P55 C, Cyrix 6 X86(L), M2, AMD K5 (over PR166), Vcore 2.5 V; Connectors; KB1: Keyboard Connector; PS;2 Mouse Connector

16
Intel P55C, Cyrix 6x86(L), M2, AMD K5 (Over PR166), V
CORE
2.5V
JP5
1
1
1
JP6
1
JP9JP7
Connectors
KB1: Keyboard Connector
A 5-pin female DIN keyboard connector is located at the
upper right corner of the motherboard. Plug the keyboard
jack direct to this connector.
PS/2 Mouse Connector
Attach PS/2 mouse cable to this 6-pin connector.
+
–
Keyboard Connector
PS/2
Mouse Connector
