Hardware Installation 11
Jumper Settings
Factory Fixed Jumpers
The following jumpers are set by the factory. Notice that the
color of these two caps are BLACK.
Jumpers Factory settings
JP6, JP5 Factory fixed at 2Ð3
J7 Factory fixed at Short
JP12: Monitor Selection
Set JP12 to select the either a color or monochrome monitor.
Monitor Type JP12
Monochrome Open
Color
(default)
Close
Notice that the color of the cap is BLACK.
+
–
JP12
