18
FDC1: Floppy Drive Connector
The system board has a 2x17-pin floppy drive connector,
FDC1. Connect one end of a floppy drive cable to this
connector and the other end to a floppy drive.
IDE1/IDE2: Primary/Secondary IDE Connectors
The system board has a 32-bit Enhanced PCI IDE Controller
that provides for two HDD connectors, IDE1 (primary) and
IDE2 (secondary).
+
–
FDC1
1
IDE2
IDE1
1
1
