JP14: Cache Memory Select
The board has 256K installed and this jumper is set open. If
you want to upgrade to 512K, you need to short this jumper
and add another 256K module.
Notice that the color of the cap is WHITE.
+
–
JP14 JP14
256K
(default)
512K
Note: Contact your board manufacturer for the Pipelined burst
module information in order to get the best compatibility
and stability of the board.
