SOLTEK SL-52D2 - JP3: Clear CMOS Data; JP8: ISA Clock Select

Hardware Installation 13
JP3: Clear CMOS Data
Clear the CMOS memory by shorting this jumper
momentarily; then remove the cap to retain new settings.
COMS Data JP3
Clear Data Close
Retain Data
(default)
Open
JP8: ISA Clock Select
This jumper sets the ISA clock of different CPUs.
Clock JP8
PCI Clock/3 Open
PCI Clock/4 Close
Notice that the cap color of JP8 is RED.
+
–
JP8
JP3
