Award BIOS Setup 35
Integrated Peripherals
Integrated Peripherals option changes the values of the
chipset registers. These registers control system options in
the computer.
1. Choose ÒINTEGRATED PERIPHERALSÓ from the Main
Menu and a screen with a list of options appears.
ROM PCI/ISA BIOS
INTEGRATED PERIPHERALS
AWARD SOFTWARE, INC.
ESC : Quit ↑ ↓ → ←: Select Item
F1 : Help PU/PD/+/– : Modify
F5 : Old Values (Shift)F2 : Color
F6 : Load BIOS Defaults
F7 : Load Setup Defaults
IDE HDD Block Mode : Enabled
IDE Primary Master PIO : Auto
IDE Primary Slave PIO : Auto
IDE Secondary Master PIO : Auto
IDE Secondary Slave PIO : Auto
On-Chip Primary PCI IDE: Enabled
On-Chip Secondary PCI IDE: Enabled
PCI Slot IDE 2nd Channel : Enabled
USB Controller : Disabled
Onboard FDD Controller : Enabled
Onboard Serial Port 1 : Auto
Onboard Serial Port 2 : Auto
UART 2 Mode : Standard
IR Function Duplex+ : Half
RxD, TxD Active+ : Lo, Lo
Onboard Parallel Port : 378H/IRQ7
Onboard Parallel MODE : SPP
ECP Mode Use DMA* : 3
Parallel Port EPP Type* : EPP1.7
2. Use one of the arrow keys to move between options and
modify the selected options by using PgUp/PgDn/+/Ð
keys.
A short description of screen options follows:
IDE HDD Block
Mode
Choose Enabled (default) or
Disabled. If your hard disk size is
larger than 540MB, choose Enabled,
and, if you are using the IDE HDD
Auto Detection option, the BIOS
will choose this option
automatically. (Note: Some HDDs
of old models donÕt provide this
feature.)
