USE OF THE STORAGE CABINET AS300
D0716C-EN
1. Start the identification process using the barcode reader
(or RFID system) and the badge associated with the
Operator level.
After the beep, screen 1 appears.
2. Select the reference of the endoscope to be removed
from the list by pressing the relevant button.
When handling and in particular when inserting and
removing endoscopes we recommend that you
wash and sanitize your hands according to the
applicable protocol.
3. Wait for the carousel to come to a stop (screen 2)
4. Validate if the model is correct (screen 3)
The selected endoscope is automatically presented in front of
the door.
Open the electromagnetic door lock.
5. Disconnect the connector from the central cylinder;
detach the selected endoscope with the connectors still
attached.
6. Close the door.
Endoscopes must be removed one after another. Never
remove more than one endoscope at a time.
The validation ticket will be printed automatically.
At this stage it is important to check again that all
the connections for irrigating the internal
channels of the endoscope are still connected to
the different points on the endoscope. If not, the
storage cycle must be considered invalid.
Screen 4 appears automatically while the validation ticket is
being printed.
This screen appears for 20 seconds and is then
refreshed for the following endoscope removal.
Cycle valid = the endoscope can be used without repeat
disinfection.
Cycle invalid = the endoscope must be disinfected again.
SCREEN 1
SCREEN 2
SCREEN 3
SCREEN 4
It is impossible to interrupt the removal operation once the electromagnetic door lock is released.
In the event of an error during removal:
• Removal of an endoscope not corresponding to the selected position
• Incorrect disconnection of the medical air supply connection
When closing the door, the message « endoscope not properly disconnected » appears:
1. Reconnect the endoscope removed by mistake and disconnect the endoscope corresponding to the
initial choice.
2. Check that the end of the connector is not still connected to the coupling.
3. Close the door.
