30
Edition: 2021-04 Original document - Mi-205 EN
Danger!
Risk of injury!
Observe movements of the valve disc.
Keep hands, tools and other objects away from the area where the valve disc moves. The valve
with valve disc mounted may work as a cutting tool. Do not leave any foreign objects in the
valve body. The valve disc of the butterfly valve always works as a separate device. There is no
difference whether an actuator is installed or not. The position of the disc may change during
transport or handling of the butterfly valve.
1 End stop bolt 4 Clamping ring
2 End stop bolt 5 Bracket
3 Bolt 6 Bolt
Fig.5-11 Assembly of the actuator (schematic diagram)
3
4
5
6
