1.1.2 Symbols and signs
Symbols and signs are used in this operating manual to provide fast access to
information.
1.1.2.1 Symbols and signs in the text
Symbol Denotation Explanation
Operating instructions This means there is an action to be carried out.
1.
2.
Operating instructions,
multi-step
Work instructions must be carried out in the
sequence shown.
Deviations from the sequence shown may result in
damages to the valve and accidents.
•
–
Lists, two-stage No activities are linked with lists.
➔
Cross-reference References to images, tables, other sections or other
instructions.
Tab.1-1 Symbols in the text
