48
Edition: 2021-04 Original document - Mi-205 EN
1
2
6.8 Adjustment of the end positions on gear
Danger!
Risk of injury!
Observe movements of the disc.
Keep hands, tools and other objects away from the area where the disc moves when the
actuator is connected to compressed air system. Single action actuators may move to “open” or
“closed” position without being connected to the air system.
1 End position bolt “open” position 2 End position bolt “closed” position
Fig.6-9 End position bolts on gear actuator
Attention!
Damage to PTFE seats!
While adjusting disc valves equipped with PTFE seats keep attention not to close the valve to
firm. This causes damage to the seat!
