USER GUIDE
USER GUIDE
2 User Guide
Getting to know your mixer
The following section will display and explain the features of S1 Mixer from input through to
output. Please read this section thoroughly to acquaint yourself thoroughly with the myriad
of options available. However, if you are more interested in setting it up skip to the next
chapter - Mixer Applications.
The following section is divided into these parts:
System block diagrams – If you are electronically inclined, dive into the inner workings 1.
of the S1. Page 6.
Input channel types – Discover the type of Inputs available to you . Page 9.2.
Front panel channel features – All channel knobs and buttons explained. Page 12.3.
Metering, monitors and headphones – Explore the Metering options and find out 4.
where to plug in your monitors and stick your headphone jack. Page 17.
Output buses – Understand all the output options you have. Page 18.5.
