CONNECTORS AND CABLING
CONNECTORS AND CABLING
Auxiliary Output Connector
Pin 1: Chassis ground.
Pin 2: Aux 1 left phase.
Pin 3: Aux 1 right phase.
Pin 4: Aux 2 left phase.
Pin 5: Aux 2 right phase.
Pin 6: Aux 1 left non-phase.
Pin 7: Aux 1 right non-phase.
Pin 8: Aux 2 left non-phase.
Pin 9: Aux 2 right non-phase.
Mono Remote Connector
Pin 1: Channel 1 Mic Start
Pin 2: Channel 1 Line Start
Pin 3: GPIO 1
Pin 4: Channel 2 Line Stop
Pin 5: DGND
Pin 6: Channel 3 Mic Start
Pin 7: Channel 3 Line Start
Pin 8: GPIO 3
Pin 9: Channel 4 Line Stop
Pin 10: DGND
Pin 11: Channel 5 Mic Start
Pin 12: Channel 5 Telco Start
Pin 13: GPIO 5
Pin 14: Channel 1 Line Stop
Pin 15: DGND
Pin 16: Channel 2 Mic Start
Pin 17: Channel 2 Line Start
Pin 18: GPIO 2
Pin 19: Channel 3 Line Stop
Pin 20: DGND
Pin 21: Channel 4 Mic Start
Pin 22: Channel 4 Line Start
Pin 23: GPIO 4
Pin 24: Channel 5 Line Stop
Pin 25: DGND
