CONNECTORS AND CABLING
CONNECTORS AND CABLING
Stereo Remote Connector
Pin 1: Channel 6 Input 1 Start
Pin 2: Channel 6 Input 2 Start
Pin 3: DGND
Pin 4: Channel 7 Input 1 Stop
Pin 5: Channel 7 Input 2 Stop
Pin 6: Channel 8 Input 1 Start
Pin 7: Channel 8 Input 2 Start
Pin 8: DGND
Pin 9: Channel 9 Input 1 Stop
Pin 10: Channel 9 Input 2 Stop
Pin 11: Channel 10 Input 1 Start
Pin 12: Channel 10 Input 2 Start
Pin 13: DGND
Pin 14: Channel 6 Input 1 Stop
Pin 15: Channel 6 Input 2 Stop
Pin 16: Channel 7 Input 1 Start
Pin 17: Channel 7 Input 2 Start
Pin 18: DGND
Pin 19: Channel 8 Input 1 Stop
Pin 20: Channel 8 Input 2 Stop
Pin 21: Channel 9 Input 1 Start
Pin 22: Channel 9 Input 2 Start
Pin 23: DGND
Pin 24: Channel 10 Input 1 Stop
Pin 25: Channel 10 Input 2 Stop
