TECHNICAL SPECIFICATION
TECHNICAL SPECIFICATION
6 Technical Specication
Input / Output Impedances
Mic Input: > 1k5Ω electronically balanced
Mono Line Input: > 20kΩ electronically balanced.
Stereo Line Input: > 20kΩ electronically balanced.
PGM Output: < 50Ω electronically balanced
Monitor Outputs: < 75Ω unbalanced.
AES Input/Output: 110Ω
S/PDIF Input/Output: 75Ω
BNC Wordclock input: 50Ω
Input / Output Gain Range
Mic Input: Preset pot +21dB to +64dB ref -50dBu,
TRIM pot ± 12dB
Mono Line Input: Switch 0dB to +10dB ref 0dBu,
TRIM pot ± 12dB
Stereo Line Input: Switch 0dB to +10dB ref 0dBu,
TRIM pot ± 12dB
Telco Input: Switch 0dB to +10dB ref 0dBu,
TRIM pot ± 12dB
Telco Output:
Stereo Cleanfeed Input: Switch 0dB to +10dB ref 0dBu,
TRIM pot ± 12dB
Stereo Cleanfeed Output:
Digital Input: 0dBFS = +18dBu on input;
TRIM pot ± 12dB
Digital Output: 0dBFS = +18dBu
