CONNECTORS AND CABLING
CONNECTORS AND CABLING
Connector Pin Outs
External Inputs Connector
Pin 1: Chassis ground.
Pin 2: Ext 1 left phase.
Pin 3: Ext 1 right phase.
Pin 4: Ext 2 left phase.
Pin 5: Ext 2 right phase.
Pin 6: Ext 1 left non-phase.
Pin 7: Ext 1 right non-phase.
Pin 8: Ext 2 left non-phase.
Pin 9: Ext 2 right non-phase.
Meterbridge Port
Pin 1: METER AUDIO LEFT Audio being displayed on the S1 meter
Pin 2: CUE PFL CONTROL Logic output to indicate a p button is pressed
Pin 3: TIMER 2 Used to start and stop timer modules. Can be used
for timing voice-overs, for example
Pin 4: TIMER 1
Pin 5: CUE / PFL AUDIO LEFT Audio for external metering
Pin 6: +15V 15v @ 200mA to power external equipment
Pin 7: AGND
Pin 8: PROGRAM AUDIO LEFT Audio for external metering
Pin 9: METER AUDIO RIGHT Audio being displayed on the S1 meter
Pin 10: CONTROL ROOM MUTE Logic signal to indicate control speakers are muted
Pin 11: REVERSE TALKBACK AUDIO Reverse talkback to presenter
Pin 12: AGND
Pin 13: CUE PFL AUDIO RIGHT Audio for external metering
Pin 14: AGND
Pin 15: PROGRAM AUDIO RIGHT Audio for external metering
Talkback Port
Pin 1: AGND
Pin 2: TALKBACK AUDIO OUT
Pin 3: TALKBACK OUT CONTROL
Pin 4: NORMALLY OPEN RELAY CONTACT
Pin 5: NORMALLY CLOSE RELAY CONTACT
Pin 6: TALKBACK AUDIO IN
Pin 7: TALKBACK IN CONTROL
Pin 8: DGND
Pin 9: WIPER RELAY CONTACT
