S1 User Handbook

TECHNICAL SPECIFICATION

Pan Range o/-3dB centre/o

Balance Range ± 6dB

Common Mode Rejection Ratio

Mic Input: >60dB typically

Digital I/O

Sync Input Sample Rate Range: 32kHz – 96kHz

Output Sample Rates (Using

Onboard Clock):

32kHz, 44.1kHz, 48kHz, & 96kHz

Output Sample Width: 24 bit

Output

Headphone Output Load >45 ohms, recommended 400

Maximum Output (Analogue) +26dBu balanced into 2k or greater

Weight

Unit 10.5 Kg
