SERIAL COMMUNICATION PROTOCOL
SERIAL COMMUNICATION PROTOCOL
Command Description Response
CHS:a,b,||c Congure Channel Select Buttons ACK:
A = Channel number.
1 = Ch 1
2 = selects Ch 2
etc
a = selects Ch 10
for Channels 1,2,5-10:
B = Button Control
2 = No Change
1 = Input 2
0 = Input 1
C = Lock Out Button
2 = No Change
1 = Lock out
0 = Normal Operation
for Channels 3,4:
B = Button Control
2 = Input 3
1 = Input 2
0 = Input 1
C = Lock Out Button
4 = No Change
3 = Disable Stereo Line Input
2 = Disable Mono Line Input
1 = Lock out
0 = Normal Operation
CHS:a? Read Channel Select Button Status CHS:a,b,c
A = Channel number. (see above)
N.B. On Channels 1-2 ,5-10:
C will return 3 for normal operation as eectively it has the
“stereo input” selection mode disabled.
COL:a,b,c,d,e Update Intensity ACK:
A = Red
B = Green
C = Green / Orange
D = Red / Orange
E = 3MM RED LEDs
Hex Values for each colour can be in the range 0-f
COL:? Read Colour Values COL:a,b,c,d,e
