CCD-TRV128/TRV228/TRV228E/TRV328/TRV428/TRV428E
2-1 2-2
2-1. FLOW CHART
The following flow chart shows the disassembly procedure.
SECTION 2
DISASSEMBLY
HELP
HELP
HELP
NS knob
Note: When you remove Cabinet (R) Block,
or when you assembly, please slide
NS knob to the position of "ON".
Note: Flexible board is connected.
1 Lock ace
x3
2 Cabi (upper)
3 Grip belt
4 Lock ace
x3
5 Cabi (L)
1 Lock ace
x6
2 NS knob to the position of "ON".
3 Cabi (R)
4 VC-341: CN005
5 VC-341: CN002
6 VC-341: CN008
1 Tr ipod Screw
2 Tapping P2
x2
3 Tapping P2
x6
4 Claw
5 CF-5100
6 Tapping P2
x4
7 Claw
x2
8 P Cabi (C)
9 Tapping P2
x2
q; Tapping P2
x1
qa P Cabi (M)
qs PD-204: CN6005
qd PD-204: CN6001
qf PD-204, LCD901, ND901
qg Tapping P2
x4
qh Hinge assy
6 Lock ace
x3
7 Claw
8 Front panel
9 FP-795: CN755, CN009
1 Lift up the EVF.
2 Tapping P2
x4
3 Down the EVF.
4 EVF block
5 EVF Cabi (upper)
6 EVF Cabi (lower)
7 FP-797: LCD902
8 EVF lens
1 Tapping P2
x4
2 Claw
x2
3 P Cabi (C)
1 VC-341: CN004
2 VC-341: CN053
3 Lock ace
x3
4 EVF/Battely panel block
5 VC-341: CN006
6 Tapping P2
x1
7 Lock ace
x1
8 SS-5100
1 VF blind sheet
2 VC-341: CN402, CN403, CN481
3 VC-341: CN401
4 Screw (M1.7)
x2
5 Claw
6 Open the VC-341.
7 VC-341: CN404
8 VC-341
1 Screw (M1.7)
x3
2 CS frame
1 VC-341: CN151
2 VC-341: CN201
3 Lens sheet
4 Lock ace
x2
5 Boss
6 Lens LSV-820A
1
5
2
1
3
4
4
6
6
7
9
8
1
1
2
4
5
6
3
qd
qg
2
3
4
6
7
9
q;
qs
1
5
3
3
6
7
1
2
2
3
4
5
6
7
8
1
1
1
2
4
5
8
4
1
2
3
5
6
8
qa
qf
qh
1
2
2
3
4
7
5
6
2
1
3
8
To Next Page
