5-18
Ref. No. Part No. Description Ref. No. Part No. Description
CCD-TRV128/TRV228/TRV228E/TRV328/TRV428/TRV428E
C487 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C488 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C489 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C490 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C491 1-164-878-11 CERAMIC CHIP 150PF 5% 50V
C492 1-164-872-11 CERAMIC CHIP 82PF 5% 50V
C493 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C494 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C495 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C496 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C497 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C498 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C500 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C505 1-100-249-11 CERAMIC CHIP 0.01uF 10% 16V
C507 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C508 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C509 1-164-941-11 CERAMIC CHIP 0.0047uF 10% 16V
C513 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V
C514 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C515 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C601 1-100-249-11 CERAMIC CHIP 0.01uF 10% 16V
C602 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
C603 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
C604 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C605 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C606 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C607 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C609 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C610 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C611 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C614 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C615 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C616 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C617 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
(TRV328/TRV428/TRV428E)
C617 1-218-977-11 RES-CHIP 100K 5% 1/16W
(Note) (TRV128/TRV228/TRV228E)
C618 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
(TRV328/TRV428/TRV428E)
C618 1-218-977-11 RES-CHIP 100K 5% 1/16W
(Note) (TRV128/TRV228/TRV228E)
C619 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C620 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C622 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C623 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C624 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C708 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C709 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C710 1-164-941-11 CERAMIC CHIP 0.0047uF 10% 16V
C711 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C712 1-164-856-81 CERAMIC CHIP 18PF 5% 50V
C713 1-100-249-11 CERAMIC CHIP 0.01uF 10% 16V
C714 1-164-856-81 CERAMIC CHIP 18PF 5% 50V
C715 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C801 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C802 1-124-779-00 ELECT CHIP 10uF 20% 16V
C805 1-124-779-00 ELECT CHIP 10uF 20% 16V
C806 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C807 1-124-779-00 ELECT CHIP 10uF 20% 16V
C808 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C810 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C811 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C812 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C814 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C815 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C816 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C817 1-124-779-00 ELECT CHIP 10uF 20% 16V
C818 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V
C819 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C820 1-126-602-11 ELECT CHIP 3.3uF 20% 50V
C821 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V
C822 1-127-715-91 CERAMIC CHIP 0.22uF 10% 16V
C823 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C825 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C826 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C828 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C829 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C830 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C831 1-164-941-11 CERAMIC CHIP 0.0047uF 10% 16V
C832 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C833 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C834 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C835 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C836 1-127-715-91 CERAMIC CHIP 0.22uF 10% 16V
C837 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C839 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C840 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C841 1-124-779-00 ELECT CHIP 10uF 20% 16V
C842 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C843 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C844 1-164-870-11 CERAMIC CHIP 68PF 5% 50V
C845 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C846 1-126-209-11 ELECT CHIP 100uF 20% 4V
C847 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C848 1-126-209-11 ELECT CHIP 100uF 20% 4V
C849 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C850 1-100-696-91 CERAMIC CHIP 1uF 10% 6.3V
< CONNECTOR >
CN002 1-794-998-31 PIN, CONNECTOR 20P
CN004 1-779-328-21 CONNECTOR, FFC/FPC 8P
CN005 1-779-335-21 CONNECTOR, FFC/FPC 22P
CN006 1-766-677-21 CONNECTOR, FFC/FPC 16P
CN007 1-766-677-21 CONNECTOR, FFC/FPC 16P
CN008 1-794-057-21 PIN, CONNECTOR (PC BOARD) 2P
CN009 1-818-072-11 CONNECTOR, FFC/FPC (ZIF) 30P
CN053 1-573-806-21 PIN, CONNECTOR (1.5MM)(SMD) 6P
CN151 1-779-331-11 FFC/CONNECTOR, FPC (LIF (NON-ZIF)) 14P
CN201 1-750-360-21 CONNECTOR, FFC/FPC (ZIF) 24P
* CN401 1-580-055-21 PIN, CONNECTOR (SMD) 2P
CN402 1-766-646-21 CONNECTOR, FFC/FPC 10P
CN403 1-816-179-11 FFC/CONNECTOR, FPC (ZIF) 22P
CN404 1-766-345-21 CONNECTOR, FFC/FPC 15P
CN481 1-766-647-21 CONNECTOR, FFC/FPC 11P
VC-341
Note: Resistors are mounted to the location
where C617, C618 are printed.
(TRV128/TRV228/TRV228E only)
To Next Page
