Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
32
CDP-XE270/XE370
< SWITCH >
S151 1-572-086-11 SWITCH, LEAF (LOAD OUT)
S152 1-572-086-11 SWITCH, LEAF (LOAD IN)
**************************************************************
A-4725-617-A MAIN BOARD, COMPLETE
*********************
7-685-871-01 SCREW +BVTT 3X6 (S)
< CAPACITOR >
C601 1-128-547-11 ELECT 6800uF 20% 16V
C602 1-126-767-11 ELECT 1000uF 20% 16V
C603 1-128-576-11 ELECT 100uF 20% 63V
C604 1-161-494-00 CERAMIC 0.022uF 25V
C605 1-161-494-00 CERAMIC 0.022uF 25V
C606 1-164-159-11 CERAMIC 0.1uF 50V
C607 1-164-159-11 CERAMIC 0.1uF 50V
C608 1-126-934-11 ELECT 220uF 20% 10V
C609 1-161-494-00 CERAMIC 0.022uF 25V
C610 1-136-165-00 MYLAR 0.1uF 5% 50V
C612 1-161-494-00 CERAMIC 0.022uF 25V
C616 1-126-916-11 ELECT 1000uF 20% 6.3V
C618 1-126-933-11 ELECT 100uF 20% 16V
C619 1-104-656-51 ELECT 2200uF 20% 6.3V
0C620 1-113-924-11 CERAMIC 0.0047uF 20% 250V
C631 1-161-494-00 CERAMIC 0.022uF 25V
C641 1-126-964-11 ELECT 10uF 20% 50V
C642 1-126-935-11 ELECT 470uF 20% 10V
C651 1-126-935-11 ELECT 470uF 20% 10V
C653 1-104-666-11 ELECT 220uF 20% 25V
C654 1-164-159-11 CERAMIC 0.1uF 50V
C657 1-164-159-11 CERAMIC 0.1uF 50V
C658 1-164-159-11 CERAMIC 0.1uF 50V
C659 1-161-494-00 CERAMIC 0.022uF 25V
C663 1-162-290-11 CERAMIC 470PF 10% 50V
C675 1-161-494-00 CERAMIC 0.022uF 25V
C677 1-161-494-00 CERAMIC 0.022uF 25V
C682 1-126-963-11 ELECT 4.7uF 20% 50V
C802 1-104-664-11 ELECT 47uF 20% 10V
C808 1-126-933-11 ELECT 100uF 20% 16V
C811 1-162-282-31 CERAMIC 100PF 10% 50V
C902 1-104-664-11 ELECT 47uF 20% 10V
C908 1-126-933-11 ELECT 100uF 20% 16V
C911 1-162-282-31 CERAMIC 100PF 10% 50V
< CONNECTOR >
CN621 1-784-778-11 CONNECTOR, FFC 17P
CN651 1-568-838-11 CONNECTOR, FFC 21P
< DIODE >
D601 8-719-024-99 DIODE 11ES2-NTA2B
D602 8-719-024-99 DIODE 11ES2-NTA2B
D603 8-719-024-99 DIODE 11ES2-NTA2B
D604 8-719-024-99 DIODE 11ES2-NTA2B
D605 8-719-024-99 DIODE 11ES2-NTA2B
D612 8-719-210-21 DIODE 11EQS04
D613 8-719-210-21 DIODE 11EQS04
D614 8-719-947-13 DIODE MTZJ-T-72-4.7B
D615 8-719-911-19 DIODE 1SS119-25
D616 8-719-911-19 DIODE 1SS119-25
D631 8-719-983-63 DIODE MTZJ-T-72-3.3B
D641 8-719-983-84 DIODE MTZJ-T-72-30D
D643 8-719-109-85 DIODE RD5.1ESB2
D681 8-719-911-19 DIODE 1SS119-25
D682 8-719-911-19 DIODE 1SS119-25
D691 8-719-911-19 DIODE 1SS119-25
D692 8-719-911-19 DIODE 1SS119-25
< IC >
IC601 8-759-039-69 IC uPC7805AHF
IC602 8-749-011-78 IC BA17807T
IC603 8-759-165-81 IC PST600D-T
IC631 8-759-598-69 IC BA6956AN
IC651 8-749-921-12 IC GP1F32T (DIGITAL OUT OPTICAL)
IC801 8-759-711-35 IC NJM4580D
< JACK >
J681 1-785-868-11 JACK, PIN 2P (ANALOG OUT)
< COIL >
L651 1-414-151-21 INDUCTOR 470uH
< TRANSISTOR >
Q642 8-729-041-38 TRANSISTOR 2SB1241TV2Q
Q681 8-729-029-56 TRANSISTOR DTA144ESA
Q682 8-729-922-37 TRANSISTOR 2SD2144S-UVW
Q691 8-729-029-56 TRANSISTOR DTA144ESA
Q692 8-729-922-37 TRANSISTOR 2SD2144S-UVW
< RESISTOR >
R606 1-247-769-11 CARBON 2.7 5% 1/4W
R607 1-247-769-11 CARBON 2.7 5% 1/4W
R611 1-249-429-11 CARBON 10K 5% 1/4W
R612 1-249-411-11 CARBON 330 5% 1/4W
R631 1-249-427-11 CARBON 6.8K 5% 1/4W
R632 1-215-421-00 METAL 1K 1% 1/4W
R641 1-249-432-11 CARBON 18K 5% 1/4W
R642 1-249-432-11 CARBON 18K 5% 1/4W
R646 1-249-432-11 CARBON 18K 5% 1/4W
R647 1-247-807-31 CARBON 100 5% 1/4W
R648 1-247-807-31 CARBON 100 5% 1/4W
R651 1-247-807-31 CARBON 100 5% 1/4W
R652 1-247-807-31 CARBON 100 5% 1/4W
R653 1-247-807-31 CARBON 100 5% 1/4W
R681 1-249-441-11 CARBON 100K 5% 1/4W
R682 1-249-419-11 CARBON 1.5K 5% 1/4W
R691 1-249-441-11 CARBON 100K 5% 1/4W
R692 1-249-419-11 CARBON 1.5K 5% 1/4W
R804 1-215-445-00 METAL 10K 1% 1/4W
R805 1-215-445-00 METAL 10K 1% 1/4W
R806 1-215-445-00 METAL 10K 1% 1/4W
R809 1-249-441-11 CARBON 100K 5% 1/4W
R810 1-249-414-11 CARBON 560 5% 1/4W
R812 1-247-807-31 CARBON 100 5% 1/4W
LOADING MAIN
