Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
33
CDP-XE270/XE370
R904 1-215-445-00 METAL 10K 1% 1/4W
R905 1-215-445-00 METAL 10K 1% 1/4W
R906 1-215-445-00 METAL 10K 1% 1/4W
R909 1-249-441-11 CARBON 100K 5% 1/4W
R910 1-249-414-11 CARBON 560 5% 1/4W
R912 1-247-807-31 CARBON 100 5% 1/4W
**************************************************************
1-681-131-11 POWER SW BOARD
****************
< CAPACITOR >
0 C621 1-113-924-11 CERAMIC 0.0047uF 20% 250V
< CONNECTOR >
* CN601 1-580-230-31 PIN, CONNECTOR (PC BOARD) 2P
CN602 1-564-321-00 PIN, CONNECTOR 2P
< SWITCH >
0 S601 1-762-581-11 SWITCH, AC POWER PUSH (1KEY) (POWER)
**************************************************************
MISCELLANEOUS
**************
3 1-500-386-11 FILTER, CLAMP (FERRITE CORE)
0 6 1-696-845-11 CORD, POWER (AUS)
0 6 1-775-787-51 CORD, POWER (AEP, UK, SP)
0 6 1-783-531-31 CORD, POWER (US, CND)
7 1-590-243-11 WIRE (FLAT TYPE) (21 CORE) (XE270: US)
7 1-823-359-11 WIRE (FLAT TYPE) (21 CORE)
(XE270: CND, AEP, UK, SP, AUS/XE370)
58 1-773-041-11 WIRE (FLAT TYPE) (17 CORE)
508 1-452-925-21 MAGNET ASSY
0 555 1-796-033-12 OPTICAL PICK-UP (PXR-104X)
0 555 8-848-483-21 OPTICAL PICK-UP (KSS-213C/C2RP)
556 1-782-817-11 WIRE (FLAT TYPE) (16 CORE)
560 X-4917-523-3 BASE (OUTSERT) ASSY
(including M101 (spindle))
M102 X-4917-504-1 MOTOR ASSY (SLED)
M151 A-4604-363-A MOTOR (L) ASSY (LOADING)
0 T601 1-437-257-11 TRANSFORMER, POWER (US, CND)
0 T601 1-437-258-11 TRANSFORMER, POWER (AEP, UK, SP, AUS)
************************************************************
ACCESSORIES
************
0 1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (UK)
1-418-765-11 REMOTE COMMANDER (RM-DX740) (XE370)
1-776-263-11 CORD, CONNECTION (RCA AUDIO CORD)
4-233-601-11 MANUAL, INSTRUCTION (ENGLISH, FRENCH)
(XE270: CND, AEP/XE370: AEP)
4-233-601-21 MANUAL, INSTRUCTION (GERMAN, SPANISH,
DUTCH, SWEDISH, ITALIAN, POLISH) (AEP)
4-233-601-61 MANUAL, INSTRUCTION
(TRADITIONAL CHINESE) (SP)
4-233-601-71 MANUAL, INSTRUCTION
(ENGLISH) (US, UK, SP, AUS)
4-983-956-01 COVER, BATTERY(for RM-DX740) (XE370)
MAIN POWER SW
Note: When you exchange Ref. No. 555, please be sure
to refer to “Supplement-1”.
Ver. 1.4
